Specifications:
Sensor OV9281 OV9282
Optical size Type 1/4 inch
Pixel Size: 3um*3um
Shutter Type Global Shutter
Max Sensor Resolution 1280*800
Color Filter Array: Noe(Monochrome)
Resolution and Frame Rate RAW8/RAW 10: 640*480@ 260fps, 1280*720@144fps, 1280*800 @120fps
Output RAW 8/RAW 10
Focus Type Manual
Focus 50cm--- INF
Lens: f/2.0, EFL: 2.35mml; FOV 89.5 degree
IR Sensitivity: build-in 650nm IR-Cut filter, sensitive to visible light only.
Sensor features:
Omnivision OV9281 and OV9282 are high-speed global shutter image sensors that bring 1-megapixel resolution to a wide range of consumer and industrial computer vision applications, including augmented reality( AR), virtual reality (VR), collision avoidance in drones, barcode scanning and factory automation. The OV9281 and OV9282 feature a high-speed global shutter pixel with best in class near infrared quantum efficiency to meet high resolution and low latency requirements.
The OV9281 has a chief ray angle (CRA) of 9 degrees and comes in a chip scale package. The OV9282 features a CRA of 27 degrees and is available in a reconstructed wafer format. Both sensors are currently available in volume production.
